Lowrance StructureScan 3D Module With Transducer

See your targets in 3D

The new Lowrance StructureScan 3D Module allows
you to see fish, structure and bottom contour in a stunning
three-dimensional view. StructureScan 3D imaging scans underwater
terrain and fish-holding structure to create a high-resolution,
180-degree, three-dimensional view beneath your boat. With this
unique imaging view, you’ll get a better understanding of where
fish and structure are located in relation to your boat. The
picture-like, three-dimensional views are displayed on the Lowrance
HDS Gen3 series of fishfinder/chartplotters, when used in
combination with the SideScan 3D Skimmer transducer and
StructureScan 3D module.

StructureScan 3D
StructureScan 3D is powered by a multi-beam sonar technology that
produces revealing images with stunning detail by converting scans
of underwater terrain and fish-holding structure into
high-resolution, 180-degree, three-dimensional views.

Easy-to-Understand Sonar Images
View 3D images from any angle with ScanTrack pan-tilt-rotate
control using on-screen touch commands and easy-to-use, preset
viewing positions.

Find Key Fishing Areas Faster
StructureScan 3D allows anglers to more easily understand where
fish and fish-holding structure are located in relation to their
boat. By slowly idling over a potential fishing area with the wide,
180-degree scanning range, anglers can quickly search for key areas
and cover ─ such as abrupt depth changes, points, ditches,
rockpiles, brushpiles, weedbeds standing timber, wrecks and
more.

Unrivalled SideScan Image Clarity
To ensure the clearest possible SideScan views, the StructureScan
3D transducer design has been enhanced with an increased number of
sensors for greater imaging performance.

High Definition (HD) and Super-Wide 3D Scanning
The contours below the water’s surface can be shown to the sides of
the boat ─ up to 600 feet port and starboard ─ with incredibly
detailed, high-definition views. StructureScan 3D provides multiple
views, including two-dimensional DownScan Imaging and StructureScan
HD and the new, realistic three-dimensional views. Using preset
virtual point-of-view angles or ScanTrack pan-tilt-rotate control
mode, you can adjust the view and perspective beneath your boat.
Combine custom HD and 3D views to increase your understanding of
how fish relate to cover and to search fishing areas more
effectively.

Leading Edge Scanning Reference
The Leading Edge scanning reference provides a clear graphical
illustration of sonar beams as they intersect with bottom contours.
The depth and range of the most recently scanned area are shown as
red fan-shaped markers directly under the boat. Leading Edge also
includes a depth scale that shows greater depth detail as you zoom
in, giving you a better sense of target depth.

SelectScan Target Identification
SelectScan automatically shades fish-holding cover and suspended
targets in a colour that contrasts the selected colour palette,
making target identification quicker and easier than ever
before.

Vertical Enhancement Control
Vertical Enhancement is a user-selectable scale that will apply
on-screen emphasis to vertical drops and crucial depth contour
changes, making them easier to identify relative to the surrounding
underwater terrain. Vertical Enhancement makes even the slightest
depth changes more visible.

Waypoint Overlay
Revisiting fishing areas, structure and other underwater features
is easy with the Waypoint Overlay feature. Use the waypoint keypad
to save a waypoint at the boat location, or switch to cursor mode,
and save a waypoint over specific targets, baitfish or cover.

Automatic 3D Image Settings
Fine-tuned 3D image settings are set by your HDS Gen 3 default
configuration and StructureScan 3D Module. Adjustments can be made
to Surface Clarity and Contrast settings using the on-screen
slider-bar. Surface Clarity reduces on-screen surface clutter, by
decreasing the sensitivity of the receiver near the surface.
Contrast lightens/darkens the colour palette to make fish and
structure easier to see.

Ethernet Connectivity
Ethernet ports allow connectivity for up to three networked
devices.

Lowrance StructureScan 3D Features:

• See fish, structure and bottom contour in a stunning
  three-dimensional view
• StructureScan 3D imaging scans underwater terrain and
  fish-holding structure to create a high-resolution, 180-degree,
  three-dimensional view beneath your boat
• Easy to understand sonar images
• Find key fishing areas faster
• Unrivalled SideScan image clarity
• High Definition (HD) and Super-Wide 3D Scanning
• Leading Edge Scanning Reference
• SelectScan Target Identification
• Vertical Enhancement Control
• Waypoint Overlay
• >Automatic 3D Image Settings
• SideScan 3D Skimmer transducer included

Lowrance StructureScan 3D Specifications:

Overview

• Transmit Power: Max RMS: 500W
• Cable Length: 20 ft/ 6m
• Transducer Frequencies: Enhanced 455 kHz

Sonar

• 600 feet
• EchoSounder Frequencies: Enhanced 455 kHz
• EchoSounder Output Power: Max RMS: 500W
• SideScan Imaging
  Max Range: 600 ft./183 m
  Track bottom: 35 mph/56 kph
  Mark objects: 15 mph/24 kph
  Optimum imaging: 2-8 mph/3-13 kph
• DownScan Imaging
  Max Depth: 300 ft / 92 m
  Track bottom: 35 mph/56 kph
  Mark objects: 2-8 mph/3-13 kph
  Optimum imaging: 2-8 mph/3-13 kph

Technical/Environmental

• Product Weight: 1.8 lbs 0.816 kg
• Product Length: 8.26” 210 mm

Power

• Power Consumption: Max: .75A, Typical: .60A, Inrush: 4.7A
  pk
• Power Supply (Supply Voltage): 12 vDC
• Input Voltage: 10V – 17 VDC

Other

• Cable: 20 ft/ 6m
